Triconex DI 3301 Digital Input Module

Triconex DI 3301 Digital Input Module
Product status: 1.New & Original 2.In Stock

Series: Tricon Safety System

Product Description
The Triconex DI 3301 is a 32-point, commoned 24 VDC digital input module designed for the Trident safety system. It receives discrete signals from switches, contacts and other field devices and transfers their states to the system’s main processors.

The module contains three independent input-processing channels. Each channel scans all input points and sends the results to the main processors, where the data is voted before the control application uses it. Continuous diagnostics, electrical isolation and hot-spare capability support dependable operation in safety-critical installations.

Specifications

Emergency shutdown systems

Burner management systems

Fire and gas detection systems

Process interlock and permissive circuits

Valve position and limit-switch monitoring

Pressure and level switch monitoring

Motor and equipment status feedback

Turbine and compressor protection

Oil and gas production facilities

Chemical and petrochemical plants

Power-generation installations

Other Trident-based safety and critical-control systems

Key Features

Triplicated input processing
Three independent channels scan every input point and send their results to the main processors for voting.

Continuous diagnostics
Force-to-Value Diagnostic tests help identify a channel that has lost the ability to observe changing input states.

Thirty-two commoned inputs
Provides high-density monitoring of 24 VDC discrete field signals.

Fast signal acquisition
All 32 points are scanned by the analog-to-digital converter in less than 1 ms.
Input-state filtering
The specified input delay and filter characteristics help prevent short signal disturbances from affecting system logic.
