Triconex 4352B Tricon Communication Module
Item NO.: 3737914
Warranty: 1 year warranty
Condition : brand new in factory sealed box
Chat online: +86 17359287459 (whatsapp)
Email: sales6@askplc.com
Detail
- Product NameTriconex 4352B Tricon Communication Module
- Item NO.3737914
- Weight2.2400 kg = 4.9384 lb = 79.0137 oz
- CategoryOthers
- TagTRICONEX, 4352B, TCM, Communication Module
- BrandTriconex
- Creation Time2026-08-14
- Triconex 4352B is a fiber-optic Tricon Communication Module with four isolated RS-232/RS-485 serial ports and two 100 Mbps fiber Ethernet ports.
|
TRICON COMMUNICATION MATRIX
Triconex 4352B
Tricon Communication Module (TCM)
|
MODULE ID
4352B
FIBER TCM
|
|
OVERVIEW
|
Triconex 4352B is a fiber-optic Tricon Communication Module used to provide serial and Ethernet communication interfaces for a Tricon system. Its front-panel ports support connections to engineering, Modbus, time-synchronization and peer communication networks defined in the Tricon communication architecture. |
01 INTERFACE MATRIX
|
FIBER NETWORK LAYER
2 × Ethernet
100 Mbps fiber-optic ports with MT-RJ connectors for 62.5/125 µm fiber cable.
|
SERIAL DEVICE LAYER
4 × Serial
Optically isolated RS-232/RS-485 ports with DB-9 connectors, configurable through TriStation.
|
02 TECHNICAL DATA GRID
| Parameter | Specification |
|---|---|
| Model | 4352B |
| Module Type | Tricon Communication Module (TCM) |
| Serial Ports | 4 × optically isolated RS-232/RS-485, DB-9 |
| Serial Speed | Up to 115.2 Kbps per port; 460.8 Kbps aggregate |
| Network Ports | 2 × fiber-optic Ethernet, MT-RJ, 62.5/125 µm fiber |
| Fiber Ethernet Speed | 100 Mbps |
| Port Isolation | 500 VDC |
| Logic Power | Less than 10 W |
| Status Indicators | PASS, FAULT, ACTIVE, FIRM; network LINK; port TX/RX |
| Weight | 2.24 kg |
| TECHNICAL SUPPORT |
EMAIL
sales6@askplc.com
|
WHATSAPP
+86 17359287459
|
03 PROTOCOL ROUTING
| TriStation | Modbus | TCP/IP | ICMP |
| SNTP | TSAA | Trimble GPS | Peer-to-Peer |
| Time Sync | JetDirect | Modbus TCP | UDP/IP |
04 COMMUNICATION STATUS PANEL
|
PASS
Module Status
|
FAULT
Fault Indication
|
LINK
Network Status
|
TX / RX
Port Activity
|
05 RECOMMENDED MODELS
Selected from the supplied model file.
| Recommended Model | Recommended Model |
|---|---|
| XF830A | SDI-OE-S |
| LFI520 | 4100LR12 |
| SC200-00 | IC200MDD844F |
| IC200MDL650L | ZBRN2 |
| AMAX-2241 | THS710 |
| ABE7 P16T334 | 81672-01 |
| D5090S | 6FX5002-5CN01-1BA0 |
| 3500/20 125760-01 | 330930-045-02-00 |
| 6EP1332-4BA00 | KJ3001X1-CA1 |
| BMXAMI0810 | LV431564 |
|
SOURCE & SERVICE
Technical data follows the official Tricon Planning and Installation Guide and Communication Guide for Tricon v9–v10 Systems. Weight is based on the supplied product information.
|
