Triconex 3510 Pulse Input Module
Warranty: 1 year warranty
Condition : brand new in factory sealed box
Chat online: +86 17359287459 (whatsapp)
Email: sales6@askplc.com
Detail
- Product NameTriconex 3510 Pulse Input Module
- Item NO.3736695
- Weight2.3800 kg = 5.2470 lb = 83.9520 oz
- CategoryOthers
- TagTRICONEX, 3510, Pulse Input Module
- BrandTriconex
- Creation Time2026-08-12
- The Triconex 3510 Pulse Input Module processes pulse signals from field devices such as speed and flow sensors, providing reliable frequency-based measurements for Tricon safety and critical control applications.
New & Original | In Stock | Ready to Ship
Email: sales6@askplc.com/WhatsApp: +86 17359287459
|
Triconex 3510 Details |
|
|
The Triconex 3510 Pulse Input Module provides eight sensitive, high-frequency inputs for processing signals from non-amplified magnetic speed sensors. It detects voltage transitions, counts incoming pulses within a selected time window, and converts the result into frequency or rotational-speed data for the Tricon Main Processors. |
|
|
Module Type |
Pulse Input Module |
|
Input Points |
8, non-commoned |
|
Frequency Range |
20–20,000 Hz |
|
Pulse-count Resolution |
1 μs |
|
Input Processing |
Three isolated channels |
|
Typical Sensor Type |
Non-amplified magnetic speed sensor |
|
Measurement Output |
Frequency or RPM |
|
Diagnostics |
Continuous channel diagnostics |
|
Fault Indication |
Front-panel FAULT indicator and chassis alarm |
|
Spare Capability |
Supports a hot-spare module |
Key Features
Eight high-frequency inputs handle signals from multiple rotating-equipment speed sensors.
TMR processing architecture independently processes input data through three isolated channels.
Accurate speed calculation converts pulse counts into frequency or RPM values.
Continuous diagnostics monitor every channel and report detected faults through the module and chassis alarms.
Hot-spare support provides an additional option for maintaining system availability.
Sensitive magnetic-sensor interface is optimized for non-amplified pickups installed near rotating gear teeth.
The Triconex 3510
intended for Tricon safety and critical-control installations, including:
|
Gas and steam turbines |
Oil and gas facilities |
|
Industrial compressors |
Refineries and petrochemical plants |
|
Pumps and rotating drives |
Power-generation systems |
|
Generators |
Turbomachinery control and protection systems |
