ABB SAFT121PAC SAFT 121 PAC Pulse Board

NEED HELP ? LET’S CONTACT YUKI!

PRODUCT DESCRIPTION

When resistance thermometers are used, a constant current must flow through the measuring resistor in order to create the necessary voltage drop for the evaluation. For this purpose, the basic unit 07 KT 94 provides a constant current sink, which is multiplexed to the 8 analog channels. The following figure shows the connection of Pt100 resistance thermometers in 2-wire configuration.Measuring ranges and with Pt100 as temperature sensor in 3-wire configuration The following figure shows the connection of Pt100 resistance thermometers in 3-wire configuration.The 07 KT 94 unit linearizes the Pt100 characteristic.Temperatures that exceed the measuring range cause the overflow numerical value of +32767. If the measured value is below the range, the underflow numerical value of -32767 is set. In case of a detected open-circuit the numerical value of +32767 is set. If the sensor is short-circuited, the numerical value of -32767 is set.

OUR SERVICE

1.Warranty: 1 year.

2.Lead time: 1-2 working days.3.Inventory;30 million

4.Type of payment:T/T and Western Union.

5.Courier partners: DHL, UPS, TNT, FedEx and EMS.

6.Technical specification, manuals and data sheets: Available on request.

FAQ

Q1:What is the earliest time when you can make delivery?
A:We will make delivery once received your payment.

Q2:Do you have branches in foreign countries?
A:No,but we sell to all over the world.


Q3:Are you manufactory or trading company ?
A:Trading company.

Q4:Can you offer Technical Support?
A:No, we sell hardware,not include the technical support.

Q5: Can you supply Datasheets/Literature/Technical Literature?
A: The datasheet will be shipped together with the goods .

ADVANTAGE PRODUCTS

①Allen-Bradley(USA AB)Series
②Schneider Series
③General electric Series
④Westinghouse Series
⑤SIEMENS Series
⑥ABB Robots. FANUC Robots、YASKAWA Robots、KUKA Robots、Mitsubishi Robots、OTC Robots、Panasonic Robots、MOTOMAN Robots。
⑦Westinghouse： OVATION System、WDPF System、MAX1000 system spare parts。
Conversion、I/O Signal processing、Data communication systems Digital-to-Analogue 
